Playin' around with topology and subdee...

Scritto da simon.
Domenica 07 Agosto 2011, 10:53 pm. Tag usati: , ,



In a locally Euclidean space, a 2-manifold shape is a not so difficult way to express a surface, translated into topological language (a 1-manifold is, of course, a curve).
Some holidays, a topological 3D modeler and a good working Mac Maya-based are really dangerous for my mental health, although mixing them together during a very hot week-end is way too funny as well.
Streets out there are completely deserted but... hey... we are fully populated by polygons here!

Topo_6

These digital sculptures are the result of some test presenting how 2-manifold meshes can be represented through computer graphics: they were roughly modeled using a topological modeler which guarantees consistency of polygonal surfaces. After some editing, objects are subdivided according to the Doo-Sabin algorithm.

Topo_1

This was quite interesting to me, so I believe it's worth mentioning here.
As my students know, subdees are a smart method to produce high-resolution mesh from low-resolution polygonal ones, without being as heavy as NURBS are.

Topo_4

Ed Catmull and Jim Clark invented them as quadrilateral polygons producing rounder shapes and of course they work like a charm repeating recursively their face subdivision, in order to approximate the original surface in the best way.

Topo_5

Daniel Doo and Malcolm Sabin refined a method aimed to smooth the edges of a generic morphology; considering the intersection between the polygon's face point/vertex and the two mid points related to the edges converging to the vertex, it's possible to create a new sort of offset polygon, cutting off the corners.

Topo_3

Here you can find an inspiring page to understand better what I mean.

Topo_2

Ok ok, you're right... I'd better go to the beach in summer... :)
